- Anschlüsse / Netzwerk / RJ-45
- 8x (davon: 8x 10/100/1000)
- Anschlüsse / Netzwerk / LWL
- 2x SFP
- Anschlüsse / Netzwerk / Geschwindigkeit
- 10/100/1000 MBits
- Anschlüsse / Features
- Auto-MDI/MDIX, RJ-45 Ports PoE-fähig: 8x
- Routing & Switching / Layer
- Smart Managed, Layer 2 Switching
- Routing & Switching / Switching Bandbreite
- 20 GBit/s
- Routing & Switching / Weiterleitungs-Rate
- 14,88 MPP/s
- Routing & Switching / Jumbo Frames
- 9012 byte
- Stromversorgung
- Netzteilanschluss, Stromverbrauch Betrieb: 96,2 W, PoE Gesamt-Budget: 77 W
- Feature
- IEEE 802,3 10BASE-T Ethernet; IEEE 802,3u 100BASE-TX Ethernet; IEEE 802,3ab (1000BASE-T) Ethernet; IEEE 802,3x flow control; IEEE 802,3az EEE support; IEEE 802,1p CoS support; IEEE 802,3af PoE; (GS1900-8HP/10HP/24HP/48HP); IEEE 802,3at PoE plus; (GS1900-8HP/10HP/24HP/48HP); IEEE 802,1D Spanning Tree Protocol (STP); IEEE 802,1w Rapid Spanning Tree Protocol; (RSTP); IEEE 802,1s Multiple Spanning Tree Protocol; (MSTP); Full-duplex and half duplex operation with IEEE 802,3x flow control and backpressure; Store and forward; Auto MDI/MID-X
- Abmessungen
- Breite: 250 mm x Höhe: 27 mm x Tiefe/Länge: 104 mm
- Gewicht
- 720 Gramm
