- WLAN / Standards
- Wi-Fi 3 (802,11b), Wi-Fi 3 (802,11g), Wi-Fi 4 (802,11n) - (2,4 GHz)
- Mobilfunkstandards
- 3G/UMTS, 4G/LTE
- Hardware / CPU
- Mediatek, 580 MHz, MIPS 24KEc
- Hardware / RAM
- 128 MB
- Hardware / Flash Speicher
- 16 MB
- Speicherkarten
- mini-SIM-Karte
- LEDs
- Power, LAN-Link LEDs: 4x
- LEDs / Weitere LEDs
- 5 x connection LEDs
- Feature
- Mobile Features: SIM switch, Status, SMS, Black/White list, Band management, APN, Bridge, Passthrough | Netzwerk Protokolle: VoIP passthrough support, Connection monitoring, Firewall, DHCP, QoS / Smart Queue | Management (SQM), DDNS, Network backup, Load balancing, SSHFS | TCP, UDP, IPv4, IPv6, ICMP, NTP, DNS, HTTP, HTTPS, FTP, SMTP, SSL v3, TLS, ARP, VRRP, PPP, PPPoE, UPNP, SSH, DHCP, Telnet, SMPP, SMNP, MQTT, Wake On Lan (WOL) | Authentication, Firewall, Attack prevention, VLAN, Mobile quota control, WEB filter, Access control | Static routing, Dynamic routing (BGP, OSPF v2, RIP v1/v2, NHRP) | OpenVPN, IPsec, GRE, PPTP, L2TP, Stunnel, DMVPN, SSTP, ZeroTier, WireGuard | Monitoring und Management: WEB UI, FOTA, SSH, SMS, Call, TR-069, MQTT, SNMP, JSON-RPC, MODBUS, RMS | Ping Reboot, Wget Reboot, Periodic Reboot, LCP and ICMP for link inspection | Cloud: RMS, Cloud of Things, ThingWorx, Cumulocity, Azure IoT Hub | Hotspot: Captive portal (Hotspot), internal/external Radius server, built in customizable landing page | SMS Features: SMS status, SMS configuration, send/read SMS via HTTP POST/GET, EMAIL to SMS, SMS to EMAIL, SMS to HTTP, SMS to SMS, scheduled SMS, SMS autoreply, SMPP
- Weitere Informationen
- 4-pin power socket, 9-30 VD | 2 x SIM slots (Mini SIM - 2FF), 1,8 V/3 V, external SIM holders, eSIM (Optional) | 2 x SMA für LTE, 2 x RP-SMA für WiFi Antennen | IEEE 802,11b/g/n, Access Point (AP), Station (STA)
- Hinweis
- RutOS (OpenWrt based Linux OS)
- Abmessungen
- Breite: 110 mm x Höhe: 50 mm x Tiefe/Länge: 100 mm
- Gewicht
- 297 Gramm
