- Artikelnummer
- ALT-100103510
- Zustand
- Neu
- Hersteller
- D-Link
- EAN / GTIN
- 0790069467172
- Herstellernummer
- DMS-3130-30PS/E
- Gewicht
- 6,5 kg
- Typ
- Switch
- EAN
- 0790069467172
- Hersteller-Nr.
- DMS-3130-30PS/E
- Bauform
- Rack
- Einsatzbereich
- Business
- Anschlüsse / Netzwerk / RJ-45
- 26x (davon: 16x 100/1000/2500, 8x 100/1000/2500/5000, 2x 1000/2500/5000/10000, 1x Konsolenport)
- Anschlüsse / Netzwerk / Geschwindigkeit
- 100 MBits, 1000 MBits, 2500 MBits, 5000 MBits, 10 GBits, 25 GBits
- Anschlüsse / Features
- Auto-MDI/MDIX, RJ-45 Ports PoE+-fähig: 16x, RJ-45 Ports PoE++-fähig: 8x
- Anschlüsse / Sonstige
- 1x USB-A 2,0
- Routing & Switching / Layer
- Layer 3 Routing, Layer 2 Switching
- Routing & Switching / Switching Bandbreite
- 400 GBit/s
- Routing & Switching / Weiterleitungs-Rate
- 298 MPP/s
- Stromversorgung
- Stromverbrauch inkl. PoE-Geräte: 1211,5 W, PoE Gesamt-Budget: 740 W, max. PoE Versorgung pro Port: 60 W
- Feature
- MAC Address Table: 32K (32,768) entries | Flow Control | 802,3x Flow Control | HOL Blocking Prevention | Jumbo Frames up to 9 Kbytes | 802,1AX/802,3ad Link Aggregation | Max. 32 groups per device, 8 ports per group | Spanning Tree Protocols | 802,1D STP | 802,1w RSTP | 802,1s MSTP | BPDU Filtering | Root Guard | Loop Guard | Loopback Detection | Port Mirroring | Supports One-to-One, Many-to-One | Supports Mirroring for both Tx/Rx | Supports 4 mirroring groups | Flow mirroring | Supports Mirroring for Tx/Rx | VLAN Mirroring | RSPAN | L2 Protocol Tunneling | Ethernet Ring Protection Switching (ERPS) v1/v2 || IGMP Snooping | IGMP v1/v2/v3 Snooping | Supports 1024 IGMP groups | IGMP Snooping Fast Leave | Supports 128 static IGMP groups | Per VLAN IGMP Snooping | Data Driven Learning | IGMP Snooping Querier | IGMP Authentication | IGMP Accounting | Report Suppression | MLD Snooping | MLD v1/v2 Snooping | Support 1024 MLD Groups | Host-based MLD Snooping Fast Leave | Supports 64 static MLD groups | MLD Snooping Querier | Per VLAN MLD Snooping | MLD Proxy Reporting
- Weitere Informationen
- 1x 10/100/1000BASE-T RJ-45 port for out-of-band IP management | Stacking Ports: 4
- Abmessungen
- Breite: 440 mm x Höhe: 44 mm x Tiefe/Länge: 470 mm
- Gewicht
- 6,5 kg
