- Einsatzbereich
- Business
- Anschlüsse / Netzwerk / RJ-45
- 24x (davon: 24x 10/100/1000, 10x 1000/2500/5000/10000)
- Anschlüsse / Netzwerk / LWL
- 4x SFP+
- Anschlüsse / Stacking Ports
- 4x
- Routing & Switching / Switching Bandbreite
- 168 GBit/s
- Routing & Switching / Weiterleitungs-Rate
- 125 MPP/s
- Feature
- MAC Address Table: 16K (16,384) entries, Flow Control, 802,3x Flow Control, HOL Blocking Prevention, Jumbo Frames up to 9 Kbytes, 802,1AX/802,3ad Link Aggregation, Max. 32 groups per device, 8 ports per group, Spanning Tree Protocols, 802,1D STP, 802,1w RSTP, 802,1s MSTP, BPDU Filtering, Root Guard, Loop Guard, Loopback Detection, Port Mirroring, Supports One-to-One, Many-toOne, Supports Mirroring for both Tx/Rx, Supports 4 mirroring groups, Flow mirroring, Supports Mirroring for Tx/Rx, VLAN Mirroring, RSPAN, L2 Protocol Tunneling, Ethernet Ring
- Abmessungen
- Breite: 440 mm x Höhe: 25 mm x Tiefe/Länge: 250 mm
- Gewicht
- 3,5 kg
